Modern, Sleek, and Stylish Rigid Baffles
Fabric wrapped baffles are ceiling-hung acoustical elements constructed with high-density fiberglass cores encased in acoustically transparent fabric coverings. The rigid fiberglass structure provides excellent shape retention and consistent long-term performance, ensuring that the baffles maintain their form even in challenging environments.
This core is engineered to deliver superior sound absorption properties across a wide frequency range, targeting both mid and high-frequency noise issues effectively. The outer fabric wrapping not only adds a sleek, professional finish but also allows for extensive design customization. With a wide range of fabric options, colors, and textures, these baffles can be integrated seamlessly into both contemporary and traditional architectural styles.
Fabric Options and Aesthetic Integration
We offer an extensive selection of acoustically transparent fabrics, including the most widely used and industry-trusted options:
- Guilford of Maine FR701: A classic fabric available in a broad palette of colors with a crosshatch texture.
- Guilford of Maine Anchorage: A tightly woven fabric with a clean, solid-color appearance suitable for modern or minimalist designs.
- Custom Fabrics: We can accommodate client-supplied materials or help source specialty patterns and textures to match unique project aesthetics.
All fabric options are tested for acoustic transparency and meet Class A fire-rating requirements.
Installation Methods
These baffles are lightweight yet rigid, making them simple to suspend and align. Common installation methods include:
- Eyebolts or D-rings: Factory-installed for use with cable or chain suspension from ceiling joists or other structural supports.
- Aircraft Cable Systems: Ideal for clean and adjustable suspension layouts.
- Ceiling Grid Adaptors: Compatible with drop-ceiling installations using custom mounting hardware.
Our team can provide installation drawings, hardware kits, and layout consultation to ensure optimal sound coverage and design continuity.
Specifications
Size: Standard 24" x 48", Custom Lengths up to 120", Heights up to 48"
Thickness: 1" or 2"
NRC: Up to 1.20
Mounting: Ceiling suspension system (cable or direct attach)
Fire Rating: Class A per ASTM E84
Composition
Core Material: Fiberglass Board
Facing: Hundreds of Approved Fabrics
Common Applications
- Offices
- Churches
- Mills
- Gymnasiums
- Indoor Pickleball
- More
Frequently Asked Questions
A: They’re ideal when you need excellent sound absorption with a sophisticated finish, particularly in spaces where ceilings are high and wall treatments are limited or not aesthetically appropriate. These baffles are also well-suited for environments where both aesthetics and acoustic performance are critical, such as in educational institutions, performance halls, conference centers, and worship spaces. Their design flexibility allows them to integrate beautifully into a space without compromising functionality.
A: By hanging vertically, they expose both sides to incoming sound energy, reducing reflected noise and shortening reverberation times. This leads to clearer speech and better overall acoustical comfort. Their vertical orientation disrupts long sound paths and diffuses energy throughout the space, making them especially effective in large-volume rooms. The use of high-density fiberglass and acoustically transparent fabric ensures that sound is absorbed efficiently rather than bouncing off hard surfaces, contributing to a more balanced and comfortable listening environment.
A: Depending on thickness and fabric selection, these baffles achieve NRC ratings between 0.85 and 1.20, providing significant reductions in mid- and high-frequency noise. When installed in sufficient quantities and at strategic locations, they can dramatically improve speech intelligibility and reduce ambient noise levels in noisy or echo-prone spaces. In gymnasiums and multi-purpose rooms, for example, they help control the buildup of chaotic sound energy that can interfere with communication or comfort.
A: Yes. While 2’ x 4’ is the standard, we can fabricate baffles in any size or dimension to fit your space and layout. Curved or angled shapes may also be available depending on the design needs. Custom dimensions are often required to accommodate lighting fixtures, HVAC systems, or architectural features. For projects with specific branding or visual themes, we can also apply custom fabric finishes or match corporate colors to ensure cohesion throughout the environment.
A: We offer a full suite of hanging hardware, including eyebolts, aircraft cable kits, and custom hangers for integration with ceiling grid systems. Our team will recommend the best solution based on your structure and layout. Installation can be configured to suit both aesthetic goals and acoustic performance, whether that means uniform alignment or a visually dynamic layout. We also provide layout support and engineering documents when needed to support architectural and construction teams.
A: Maintenance is minimal. Most fabrics can be vacuumed or spot cleaned with mild soap and water. Avoid abrasive cleaners that could damage the fabric or reduce acoustic transparency. For high-traffic or industrial areas, we can recommend more resilient fabric types or protective finishes. Regular dusting or vacuuming is typically sufficient to keep the baffles looking fresh, and with proper care, they can maintain their performance and appearance for many years.
A: Yes. All baffles are manufactured to meet ASTM E84 Class A fire ratings, making them safe for use in commercial, public, and institutional spaces. This ensures compliance with most local and national fire codes, and makes them suitable for use in schools, healthcare facilities, office buildings, and public venues where safety is paramount.
